Description

The FLUKE 1587/62MAX+FC Advanced Electrical Troubleshooting Kit is a complete, professional-grade solution designed for comprehensive electrical test and measurement applications. This powerful kit combines advanced insulation testing, current measurement, and non-contact temperature diagnostics in one rugged, field-ready package—delivering accuracy, safety, and efficiency for demanding industrial environments.

At the core of the kit is the Fluke 1587 FC Insulation Multimeter, which integrates full digital multimeter functionality with advanced insulation testing. It performs insulation resistance testing from 0.01 MΩ to 2.0 GΩ, with selectable insulation test voltages of 50 V, 100 V, 250 V, 500 V, and 1000 V. The meter supports PI/DAR measurements with TrendIt™ graphs, enabling detailed analysis of insulation health over time. Additional features include insulation test smoothing, auto-discharge of capacitive voltage, and a VFD low-pass filter for accurate motor drive measurements. Through the Fluke Connect™ Measurements App, users can store data, apply temperature compensation, and review results for improved diagnostics.

The kit also includes the Fluke i400 AC Current Clamp, allowing safe, non-intrusive current measurement from 1 A to 400 A AC when used with the 1587 FC. Its 1 mA/A output ensures easy-to-read measurements, while the compact design accommodates conductors up to 32 mm in diameter. The clamp is rated CAT III 1000 V / CAT IV 600 V, providing high-level user protection.

For fast and accurate temperature diagnostics, the kit features the Fluke 62 MAX+ Infrared Thermometer. It measures temperatures from -30 °C to 650 °C (-22 °F to 1202 °F) with ±1.0 °C or ±1.0% accuracy and a rapid <300 ms response time. With 12:1 optical resolution, adjustable emissivity (0.10 to 1.00), and an IP54-rated dust- and water-resistant design, it delivers reliable performance in harsh working conditions.

Product Specifications

• Product Name: Meter

• Brand: Fluke

• Part Number: 1587/62MAX+FC

• Description: Advanced Electrical Troubleshooting Kit

• Category: Industrial Instrument

• Class: Test & Inspection Equipment

• Range: Meter

• Condition: New

Key Features

• Advanced insulation testing with PI/DAR TrendIt™ analysis

• Wireless data storage and review via Fluke Connect™

• Insulation testing up to 2.0 GΩ

• Multiple insulation test voltages (50 V to 1000 V)

• VFD low-pass filter for motor drive measurements

• AC current measurement up to 400 A with i400 clamp

• Non-contact temperature measurement up to 650 °C

• High safety ratings across all instruments

• Rugged, field-ready design

Kit Includes

• Fluke 1587 FC insulation multimeter

• Fluke i400 AC current clamp

• Fluke 62 MAX+ infrared thermometer

• Remote probe

• Test leads

• Alligator clips

• K-type thermocouple

• Carrying case

• User documentation

The Fluke 1587/62MAX+FC Advanced Electrical Troubleshooting Kit delivers a complete and reliable solution for professional test and measurement, combining advanced diagnostics, enhanced safety, and proven Fluke performance in one comprehensive kit.
